ABB AC 800M controller

ABB AC 800M controller Programmable Automation Controller

ABB AC 800M controller Programmable Automation Controller


ABB AC 800M controller Programmable Automation Controller, designed to achieve high availability for control applications in the process industry

The rich function block library includes several types of control loops, including advanced control and auto- tune capabilities as well as integration for ABB drives and motors. The controller communication by means of Ethernet includes on board RNRP redundancy along with a broad set of communication modules to connect to third-party devices. A superior redundancy concept allows for fast switch-over times and topologically separated CPU-modules. Several CPU modules are available, varying in terms of processing power, memory size and redundancy supp

ABB AC 800M controller
ABB automation-AC 800M
ABB-AC 800M
ABB DCS AC800M

AC 800M

Services

Control System

New Control System is a great way to increase your productivity, minimize cost, and extend the useful life of your ABB control products and systems.


Service Agreements

Lifecycle Management Program for Distributed Control Systems




Spares and Consumables

The LifeCycle Parts Services help you minimize plant and equipment downtime. We provide cost efficient spare parts and services to ensure the best possible accessibility and continuous trouble-free operation for your system.


Advanced Services

Control systems are robust by design and development and therefore tolerant towards occurring issues. Non-optimal system settings and conditions often do not cause incidents immediately, but might result in disturbances over time.

Benefits

ABB_AUTOMATION AC800M

Full modularity and flexibility for all environments for future expansion of control applications
Compact Control Builder software offers a wide range of powerful control solutions and reusable libraries for efficient configuration

Robust design and redundancy options in all critical areas of the controller and its components eliminates single-point failures and secures maximum availability
Supports a broad range of I/O products that can be integrated into a spectrum of industrial processing applications

What’s new in AC 800M

      This year, we released Version 6 for ABB’s Process controller family AC 800M and the corresponding engineering tool Compact Control Builder M. This release includes a variety of enhancements and updates for faster communication, improved integration and efficient performance.

Windows 7 and 8 support

Version 6.0 supports Windows 8.1 and Windows Server 2012 R2. In addition, it can be used with 64-bit Windows 7 SP1 and Server 2008 R2 SP1. The new ABB Start Menu is used in Windows 8.1 to display a Windows 7 style start menu for the ABB products.

Improved security

This version supports Windows UAC (User Account Control) in default state. Installation and configuration needs administrator privileges whereas normal operation should be performed with standard user privileges to maintain a secure operation environment.

This version 6.0 is compatible with Microsoft Windows DEP (Data Execution Prevention). DEP is a security feature preventing malicious code from executing in data memory, typically buffer overflow attacks storing instructions in data memory. All executable are now digitally signed and carry ABB branding and copyright
information.


Multiple Soft Controllers

It is now possible to run up to 25 Soft Controllers simultaneously on the same PC. Peer-to-peer communication using IAC is automatically set up between the soft controllers.

Ethernet based connectivity to Satt-IO (Evolution)

Evolution for Installations of SattCon 200, SattLine 200, AC 210, AC 250 and AC 800C: The New 200-AENTR adapter connects S200 I/O to AC 800M controllers simply via Ethernet. Inbuilt Ethernet switch can daisy-chain several 200-AENTR, no external switch needed.


New controller and communication hardware

Improved auto-routing of graphical connections in the control diagram editor. The MMS communication between the AC 800M controller and OPC Server has been optimized for faster communication and less controller load.


Redundant controller in separate locations

The new BC820 redundancy module allows for up to 200m distance between redundant controllers to support physically separated installation for improved fire, water, missile protection redundancy topologies. The connection between the BC820s consists of electrical and optical link. BC820 can be used with PM862 and PM866.

ABB AC800M Product model selection

PM864K02
PM891K01-3BSE053241R1
PM825
PM803F
ABB
AC800M
PM861K01 – 3BSE018105R1
PM864AK02-3BSE018164R1
PM861AK02 – 3BSE018160R1
PM861A
ABB AC800M
PM866K01- 3BSE050198R1
PM864K01 – 3BSE018150R1
PM865K02 – 3BSE031150R6
PM820MG
ABB AC800M
PM861AK01
PM851K01
PM802F – 3BDH000002R1
PM802F
ABB AC800M
PM864AK01
PM864A-3BSE018162R1
TPM810
PM866AK02
ABB AC800M
PM856
PM860
CPM810
PM856K01
ABB AC800M
PM866K02
PM806KO1
PM866K01 – 3BSE050198R1
PM861AK02
ABB AC800M
PM865K01 – 3BSE031150R1
PM864K01 – 3BSE018161R1
PM851A
PM891 ABB AC800M
PM891K01
PM866 3BSE050200R1
PM864 AK01
PM865 ABB AC800M
